Crux DSW Comp
Specialized
Gravel
Crux DSW Comp is an alloy gravel road bike (2025), by Specialized, part of the Crux family. This model is best for a wide range of riders thanks to its fit flexibility, leaning toward a balanced riding position, and is ready for gravel routes as well as pavement. Its profile is strongest in areas like good fit flexibility for dialing in rider position, strong climbing friendliness for sustained uphill riding, and a balanced ride feel between comfort and directness. At the same time, what it gives up slightly is less emphasis on outright speed than speed-focused builds. Compare this bike with other gravel bikes on MatchBikes.com.
5.6
Rating

+4
Image 1 of 10
Score Summary
Performance
4.6
Value
6.4
Fit
6.6
Performance
Built for speed and efficiency
Speed
3.9
Very Low
Climbing Efficiency
7.9
Climber
Aerodynamics
4.7
Minimal Aero
Fit
Dialed-in Fit & Comfort
Riding Position
5.9
Balanced
Fit Flexibility
8.3
Adjustable
Ride Comfort
5.5
Balanced
Value
Value for Money
6.4
Fair Value
Surface Range
Gravel ReadySpecifications
General
Brand
Specialized
Model
Crux DSW Comp
Year
2025
Price
$2,600
Weight
9.37 kg
Category
Road
Sub Category
Gravel
Groupset
Apex XPLR
Frame
Frame
Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered head tube, threaded BB, UDH dropout
Suspension Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Suspension Type
Rigid
Drivetrain
Shift Levers
SRAM APEX, 12sp
Rear Derailleur
SRAM APEX XPLR, Mechanical
Cassette
SRAM PG 1231, XPLR, 11-44
Crank
SRAM APEX XPLR, 40t, 40t
Bottom Bracket
SRAM DUB BSA 68 Wide
Chain
SRAM APEX 12S
Wheels
Rims
Front: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples, Rear: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples
Tires
Front: Pathfinder Pro 2BR, 700x38, Rear: Pathfinder Pro 2BR, 700x38
Brakes
Brake Type
Hydraulic Disc
Brake Description
Front: SRAM APEX, Hydraulic Disc, Rear: SRAM APEX, Hydraulic Disc
Cockpit
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Handlebar
Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare
Seat
Saddle
Body Geometry Power Sport, steel rails
Seatpost
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Geometry
| Measurement | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.413 mm | 1.432 mm | 1.443 mm | 1.456 mm | 1.477 mm | 1.496 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 594 mm | 600 mm | 608 mm | 618 mm | 630 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 69 mm | 67 mm | 64 mm | 62 mm | 60 mm |
| Stack | 530 mm | 547 mm | 560 mm | 578 mm | 598 mm | 621 mm |
| Reach | 375 mm | 382 mm | 388 mm | 397 mm | 405 mm | 415 mm |
| Top Tube Length | 512 mm | 539 mm | 549 mm | 568 mm | 582 mm | 599 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 466 mm | 496 mm | 521 mm | 546 mm | 576 mm | 606 mm |
| Head Tube Angle | 70.5 ° | 71.25 ° | 71.5 ° | 72 ° | 72.25 ° | 72.5 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 147 mm | 167 mm | 190 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1008 mm | 1014 mm | 1023 mm | 1033 mm | 1045 mm | 1059 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 749 mm | 772 mm | 794 mm | 816 mm | 841 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
