Speedmax CF 7 Disc
Canyon
Triathlon
Speedmax CF 7 Disc es una bicicleta de triatlón (2024) de Canyon, parte de la familia Speedmax. Es ideal para quienes quieren sensaciones deportivas sin un ajuste de carrera extremo. Posición: deportiva. Uso: ideal en asfalto. A nivel de métricas, sobresale por muy buena relación calidad/precio, un montaje claramente orientado al aero para ir más rápido en carretera y capacidad de subida equilibrada. Frente a especialistas, el trade-off es una sensación más firme que opciones comfort-first y menos enfoque en velocidad pura que montajes más rápidos. Compara esta bici en MatchBikes.com con modelos triathlon similares.
6.4
Valoración

Image 1 of 6
Score Summary
Rendimiento
5.8
Valor
10.0
Ajuste
5.5
Rendimiento
Built for speed and efficiency
Velocidad
6.8
Media
Eficiencia en subida
5.1
Polivalente
Aerodinámica
10.0
Aero total
Ajuste
Dialed-in Fit & Comfort
Posición de conducción
7.4
Deportiva
Flexibilidad de ajuste
5.2
Moderadamente ajustable
Comodidad
2.6
Rígida de carrera
Valor
Relación calidad-precio
10.0
Valor excepcional
Rango de superficie
Solo carreteraEspecificaciones
General
Marca
Canyon
Modelo
Speedmax CF 7 Disc
Año
2024
Precio
$3,149
Peso
9.4 kg
Categoría
Road
Subcategoría
Triathlon
Grupo
105, Dura-Ace
Cuadro
Cuadro
Canyon Speedmax CF Disc, Aero frame shaped by extensive computational fluid dynamics analysis, validated in the wind tunnel with our aero partners Swiss Side. Internal cable routing, 12x142 mm through axle (rear), flat-mount disc standard., Weight: 1380 g
Horquilla de Suspensión
Canyon FK0077 CF Disc, Aero-optimised deep-profile design, 12x100 mm through axle (front), flat-mount disc standard. CT scanner tested and approved., Axle dimension: 12x100 mm, Fork steer tube diameter: 1 1/8", Tyre Clearance: 30 mm, Material: Carbon (CF)
Tipo de suspensión
Rigid
Transmisión
Palancas de Cambio
Shimano Dura-Ace 9000 TT 2x11s
Desviador Trasero
Shimano 105 R7000 SS
Desviador Delantero
Shimano 105 R7000
Cassette
Shimano 105 R7000 11-30 11s, Number of sprockets: 11
Biela
Shimano 105 R7000 4iiii Precision Powermeter, Length: 170,0 mm
Eje de Pedalier
Token Ninja Lite BB4124, Bottom bracket standard: PF 86,5, Weight: 85 g
Cadena
Shimano HG601 11-speed, Chain featuring SIL-TEC ultra-low friction surface treatment for precise shifting and improved durability.
Ruedas
Llantas
DT Swiss P 1800 Spline db, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 23 mm, Weight: 766 g | DT Swiss P 1800 Spline db SH11, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 23 mm, Weight: 901 g
Neumáticos
Continental Grand Prix 5000, 25 mm, Aeroad & Speedmax: Continental Grand Prix Force, Ultimate: Continental Grand Prix 4000 S II | Continental Grand Prix 5000 28 mm, Casing: Vectran Breaker, Compound: BlackChili, Technology: Foldable
Frenos
Tipo de freno
Hydraulic Disc
Descripción del freno
Hydraulic Disc
Palancas de Freno
SRAM S-900 Aero HRD
Cockpit
Potencia
Canyon V21 Stem Medium, Exclusively designed for our Speedmax CF range., Material: Aluminum, Length: 80 mm
Manillar
Canyon H30 Basebar Flat CF, Material: Carbon, Rise: 0 mm
Asiento
Sillín
Selle Italia Watt Superflow
Tija de Sillín
Canyon SP0048 Aero Seatpost, Speedmax time trial seatpost, deep profile, large adjustment range, UCI compliant., Weight: 300 g
Geometría
| Medida | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.289 mm | 1.291 mm | 1.295 mm | 1.305 mm | 1.299 mm |
| Front Center | 552 mm | 579 mm | 605 mm | 637 mm | 671 mm |
| Rake | 34 mm | 34 mm | 34 mm | 34 mm | 34 mm |
| Trail | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Stack | 482 mm | 519 mm | 544 mm | 578 mm | 608 mm |
| Reach | 374 mm | 402 mm | 420 mm | 443 mm | 468 mm |
| Top Tube Length | 454 mm | 489 mm | 511 mm | 540 mm | 570 mm |
| Seat Tube Angle | 80.5 ° | 80.5 ° | 80.5 ° | 80.5 ° | 80.5 ° |
| Seat Tube Length | 480 mm | 518 mm | 543 mm | 577 mm | 607 mm |
| Head Tube Angle | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 113 mm | 115 mm | 140 mm | 176 mm | 207 mm |
| Chainstay Length | 410 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 956 mm | 988 mm | 1014 mm | 1047 mm | 1081 mm |
| Bottom Bracket Drop | 52 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 273 mm | 798 mm | 816 mm | 272 mm | 272 mm |
| Wheels | 650 | 700 | 700 | 700 | 700 |
| Rider Max Height | 171 cm | 179 cm | 187 cm | 197 cm | cm |
