5500
KHS
Trail
5500 is an alloy trail mountain bike (2024), by KHS. This setup will suit a wide range of riders thanks to its fit flexibility, with a balanced riding position, and is well suited to natural trails and mixed off-road terrain. The main strengths in the metrics are strong climbing friendliness for sustained uphill riding, a comfort-leaning ride feel over longer rides, and good fit flexibility for dialing in rider position. That said, the main trade-off is less emphasis on outright speed than speed-focused builds. Compare this bike with other trail bikes on MatchBikes.com.
6.9
Rating

Image 1 of 2
Score Summary
Performance
6.6
Value
7.1
Fit
7.2
Performance
Built for speed and efficiency
Speed
3.7
Very Low
Climbing Efficiency
9.3
Mountain Goat
Suspension
7.0
High-impact ready
Fit
Dialed-in Fit & Comfort
Riding Position
5.3
Balanced
Fit Flexibility
7.0
Adjustable
Ride Comfort
7.9
Comfortable
Value
Value for Money
7.1
Fair Value
Surface Range
Natural TrailsSpecifications
General
Brand
KHS
Model
5500
Year
2024
Price
$2,959
Category
Mountain
Sub Category
Trail
Groupset
Deore, FSA
Wheels
27.5"
Frame
Frame
4-Bar Horst Link 29/650B+ 130mm, 6061 Aluminum w/Custom Formed Double Butted T/T & D/T, 1.5 Taper, 12 x 148 Rear Axle, w/Replaceable Derailleur Hanger, Internal Cable
Suspension Fork
SR Zeron 35, EQ RC Boost, Air, S:27.5”, M-L:29”, 140mm, 34mm Stanchions, Aluminum Steerer, Magnesium Lowers, Hydraulic Damp, External rebound, Lock-Out, 1.5 Taper, 15QRx110mm
Rear Shock
X-Fusion 02 Pro RL, Air, Ext Rebound, Lock-Out, 200x51
Suspension Type
Full
Drivetrain
Shift Levers
Shimano Deore, SL-M6100, 12s, Trigger, Right Only
Rear Derailleur
Shimano Deore RD-M6100
Cassette
Shimano CS-M6100, 10-51T, 12-Speed
Crank
FSA Comet, 2-pc., 30T Megatooth, Boost, S:170, M-XL:175
Bottom Bracket
FSA MegaExo Outboard Cartridge Bearing
Chain
Shimano CN-M6100
Wheels
Front Hub
Formula Sealed Bearing Aluminum Disc, 15mm, 110mm Boost
Rear Hub
Formula Sealed Bearing Aluminum Disc, Cassette, 12x148mm Boost
Rims
WTB ST= S:i35, M-L:i29 TCS, Disc, Double Wall, 32H, Tubeless-Ready
Spokes
14G Black w/Aluminum Nipples, 32x32
Tires
Kenda Regolith Pro, S:27.5 x 2.6”, M-L:29 x 2.4”, 120TPI, Folding, Tubeless-Ready
Brakes
Brake Type
Hydraulic Disc
Brake Description
Shimano MT200 Hydraulic Disc, 203/180mm Rotors Wave ‘12’
Brake Levers
Shimano MT200
Cockpit
Stem
35mm Clamp Diameter, Aluminum 3D Forged, Threadless 4-bolt, 45mm
Handlebar
Aluminum 35mm Riser, 780 x 15mm
Grips
Q2 Lock-on
Seat
Saddle
WTB Volt Medium SL
Seatpost
Kind Shock Exa-Form KSP-900-i, Integra w/Remote, Travel Adjust, 31.6mm, S:110x345, M-L:125x395
