Define AL 130 1
NS
Trail
Define AL 130 1 is an alloy trail mountain bike (2024), by NS, in the Define series. This bike is aimed at riders looking for a balanced off-road setup, leaning toward a balanced riding position, and is well suited to natural trails and mixed off-road terrain. Metric-wise, it stands out for strong climbing friendliness for sustained uphill riding, a comfort-leaning ride feel over longer rides, and capable suspension support for rougher terrain. Add this bike to compare on MatchBikes.com and see how it stacks up against similar trail models.
6.9
Rating

Image 1 of 1
Score Summary
Performance
6.7
Fit
7.3
Performance
Built for speed and efficiency
Speed
5.0
Very Low
Climbing Efficiency
8.0
Climber
Suspension
7.0
High-impact ready
Fit
Dialed-in Fit & Comfort
Riding Position
6.1
Balanced
Fit Flexibility
6.7
Moderately Adjustable
Ride Comfort
7.9
Comfortable
Value
Surface Range
Natural TrailsSpecifications
General
Brand
NS
Model
Define AL 130 1
Year
2024
Category
Mountain
Sub Category
Trail
Groupset
NX Eagle, Truvativ Descendant
Frame
Frame
NS Define AL w/ 130mm travel, AL6061-T6 + AL6066-T6, custom hydroformed tubes,
Suspension Fork
Fox Performance 34 Float Grip, 140mm travel, 3pos-Adj w/ Open Mode Adj, 15x110mm Boost, 1.5 tapered steerer tube, 44mm offset
Rear Shock
Fox Performance Float DPS 3pos-Adj Evol LV Trunnion 185x55
Suspension Type
Full
Drivetrain
Shift Levers
SRAM NX EAGLE, 12spd
Cassette
SRAM PG-1210,12spd 11-50t
Crank
Truvativ Descendant 6K DUB 170mm 32t
Bottom Bracket
SRAM DUB BSA 73mm
Chain
SRAM, 12 spd
Wheels
Front Hub
NS Rotary 15 Boost 110x15 disc (sealed bearings)
Rear Hub
NS Rotary Cassette 148x12mm Boost (sealed bearings)
Rims
Octane One Solar 29”, 32h, tubeless compatible
Spokes
Spokes w/14mm nipples
Tires
Maxxis Rekon EXO TR 29x2.4" WT
Brakes
Brake Type
Hydraulic Disc
Brake Description
SRAM G2 R 4 piston, 200mm
Cockpit
Stem
NS Quantum Lite 35 , 45mm
Handlebar
NS Bar 35, 780mm, 20mm rise
Grips
NS Hold Fast
Seat
Saddle
WTB Volt Medium Cromoly
Seatpost
Race Face Aeffect R S-125, M-150, L-170mm, 31,6mm
Geometry
| Measurement | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.416 mm | 1.345 mm | 1.282 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm |
| Front Center | 756 mm | 790 mm | 824 mm |
| Rake | 11 mm | 11 mm | 11 mm |
| Trail | 159 mm | 159 mm | 159 mm |
| Stack | 623 mm | 632 mm | 641 mm |
| Reach | 440 mm | 470 mm | 500 mm |
| Top Tube Length | 583 mm | 616 mm | 649 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 396 mm | 432 mm | 483 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1193 mm | 1227 mm | 1261 mm |
| Bottom Bracket Drop | -42 mm | -42 mm | -42 mm |
| Standover Height | 733 mm | 729 mm | 727 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
