Madone SLR 9 Gen 8
Trek
Aero
Madone SLR 9 Gen 8 es una bicicleta aero (2025) de Trek. Esta bici está orientada a quienes quieren sensaciones deportivas sin un ajuste de carrera extremo. Postura: deportiva. Terreno: ideal en asfalto. A nivel de métricas, sobresale por un montaje claramente orientado al aero para ir más rápido en carretera, gran potencial de velocidad en terreno rodador y buena capacidad de ajuste de la posición. A tener en cuenta: una sensación más firme que opciones comfort-first y el value depende más de prioridades que del precio puro. Si se parece a lo que buscas, compárala en MatchBikes.com.
6.1
Valoración

+12
Image 1 of 18
Score Summary
Rendimiento
7.3
Valor
1.6
Ajuste
6.0
Rendimiento
Built for speed and efficiency
Velocidad
8.7
Muy alta
Eficiencia en subida
6.1
Polivalente
Aerodinámica
9.2
Aero total
Ajuste
Dialed-in Fit & Comfort
Posición de conducción
6.8
Deportiva
Flexibilidad de ajuste
7.2
Ajustable
Comodidad
3.1
Firme
Valor
Relación calidad-precio
1.6
Sobrevalorada
Rango de superficie
Solo carreteraEspecificaciones
General
Marca
Trek
Modelo
Madone SLR 9 Gen 8
Año
2025
Precio
$14,175
Peso
7.05 kg
Categoría
Road
Subcategoría
Aero
Grupo
Dura-Ace Di2
Cuadro
Cuadro
900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
Horquilla de Suspensión
Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Tipo de suspensión
Rigid
Transmisión
Palancas de Cambio
Shimano Dura-Ace R9270 Di2, 12 speed
Desviador Trasero
Shimano Dura-Ace R9250 Di2, 34T max cog
Desviador Delantero
Shimano Dura-Ace R9250 Di2, braze-on, down swing
Cassette
Shimano Dura-Ace R9200, 11-30, 12 speed
Biela
Size: XS, S, Shimano Dura-Ace R9200, 52/36, 165mm length; Size: M, Shimano Dura-Ace R9200, 52/36, 170mm length; Size: ML, L, Shimano Dura-Ace R9200, 52/36, 172.5mm length; Size: XL, Shimano Dura-Ace R9200, 52/36, 175mm length
Eje de Pedalier
Praxis, T47 threaded, internal bearing
Cadena
Shimano Dura-Ace/XTR M9100, 12 speed
Ruedas
Llantas
Front: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, 100x12mm thru axle, Rear: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, Shimano 11/12 freehub, 142x12mm thru axle
Neumáticos
Size: XS, S, M, ML, L, XL, Bontrager Aeolus RSL RD, Tubeless Ready, cotton construction, aramid bead, 170 tpi, 700x28mm; Size: XS, S, M, ML, L, XL, Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x28mm
Frenos
Tipo de freno
Hydraulic Disc
Descripción del freno
Hydraulic Disc
Asiento
Sillín
Size: XS, S, Aeolus RSL, carbon rails, 155mm width; Size: M, ML, L, XL, Aeolus RSL, carbon rails, 145mm width
Tija de Sillín
Size: XS, S, M, XL, Madone aero carbon seatpost, 0mm offset, short length; Size: ML, L, Madone aero carbon seatpost, 0mm offset, long length
Componentes Eléctricos
Batería
Shimano BT-DN300
Geometría
| Medida | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.402 mm | 1.422 mm | 1.445 mm | 1.477 mm | 1.517 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm | 268 mm | 268 mm |
| Front Center | 572 mm | 577 mm | 581 mm | 580 mm | 589 mm | 604 mm |
| Rake | 50 mm | 45 mm | 45 mm | 40 mm | 40 mm | 41 mm |
| Trail | 61 mm | 62 mm | 58 mm | 59 mm | 57 mm | 57 mm |
| Stack | 507 mm | 530 mm | 546 mm | 562 mm | 582 mm | 610 mm |
| Reach | 370 mm | 378 mm | 384 mm | 389 mm | 394 mm | 402 mm |
| Top Tube Length | 517 mm | 532 mm | 545 mm | 557 mm | 568 mm | 584 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.6 ° | 73.4 ° | 73.4 ° | 73.4 ° |
| Seat Tube Length | 404 mm | 440 mm | 476 mm | 512 mm | 548 mm | 609 mm |
| Head Tube Angle | 71.6 ° | 72.2 ° | 72.9 ° | 73.5 ° | 73.8 ° | 73.9 ° |
| Head Tube Length | 100 mm | 121 mm | 136 mm | 150 mm | 172 mm | 201 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 411 mm | 412 mm |
| Wheelbase | 971 mm | 976 mm | 981 mm | 980 mm | 990 mm | 1007 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Standover Height | 704 mm | 734 mm | 762 mm | 790 mm | 820 mm | 863 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
