Planet X XLS Evo SRAM Apex AXS Carbon
planetx
Cyclocross
Planet X XLS Evo SRAM Apex AXS Carbon is a carbon cyclocross road bike (2024), by Planetx, from the Planet lineup. This bike is aimed at a wide range of riders thanks to its fit flexibility, with a balanced riding position, with a surface profile that is ready for gravel routes as well as pavement. Metric-wise, it stands out for strong value-for-money versus many similar bikes, good fit flexibility for dialing in rider position, and all-round climbing capability rather than a narrow specialty. Add this bike to compare on MatchBikes.com and see how it stacks up against similar cyclocross models.
6.4
Rating

+4
Image 1 of 10
Score Summary
Performance
5.3
Value
8.5
Fit
6.7
Performance
Built for speed and efficiency
Speed
6.8
Medium
Climbing Efficiency
6.5
All-Rounder
Aerodynamics
5.3
Minimal Aero
Fit
Dialed-in Fit & Comfort
Riding Position
5.7
Balanced
Fit Flexibility
8.2
Adjustable
Ride Comfort
5.9
Balanced
Value
Value for Money
8.5
Great Value
Surface Range
Gravel ReadySpecifications
General
Brand
planetx
Model
Planet X XLS Evo SRAM Apex AXS Carbon
Year
2024
Price
$2,481
Category
Road
Sub Category
Cyclocross
Groupset
Apex XPLR AXS, Apex AXS
Frame
Frame
Carbon
Suspension Type
Rigid
Drivetrain
Shift Levers
SRAM Apex AXS Shift Brake System With Flat Mount Caliper / Left Lever / Rear Brake / 2000mm / Flat Mount 20mm Offset
Rear Derailleur
SRAM Apex XPLR AXS 1x12 Speed Rear Mech / Max 44 Tooth
Cassette
SRAM XPLR PG-1231 12 Speed Cassette / 11-44 Tooth
Crank
SRAM Apex 1 Wide Chainset / 172.5mm / 40 Tooth
Brakes
Brake Type
Hydraulic Disc
Brake Description
SRAM Apex AXS Shift Brake System With Flat Mount Caliper / Left Lever / Rear Brake / 2000mm / Flat Mount 20mm Offset
Geometry
| Measurement | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.416 mm | 1.467 mm | 1.492 mm | 1.526 mm | 1.544 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 590 mm | 591 mm | 591 mm | 601 mm | 616 mm |
| Rake | 45 mm | 44 mm | 45 mm | 45 mm | 46 mm |
| Trail | 71 mm | 68 mm | 64 mm | 64 mm | 63 mm |
| Stack | 534 mm | 553 mm | 564 mm | 583 mm | 602 mm |
| Reach | 377 mm | 377 mm | 378 mm | 382 mm | 390 mm |
| Top Tube Length | 520 mm | 534 mm | 545 mm | 560 mm | 575 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 130 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1007 mm | 1007 mm | 1008 mm | 1018 mm | 1033 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm | 64 mm | 64 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 165 cm | 169 cm | 175 cm | 185 cm |
| Rider Max Height | 167 cm | 172 cm | 178 cm | 188 cm | 193 cm |
