Speedmax CF 8 Disc Di2
Canyon
Triathlon
Speedmax CF 8 Disc Di2 es una bicicleta de triatlón (2024) by Canyon, parte de la familia Speedmax. En uso real, es un gran match para quienes quieren sensaciones deportivas sin un ajuste de carrera extremo. Posición: deportiva. Uso: ideal en asfalto. Lo mejor en métricas MatchBikes es un montaje claramente orientado al aero para ir más rápido en carretera, muy buena relación calidad/precio y velocidad equilibrada y versátil para el día a día. El principal compromiso es una sensación más firme que opciones comfort-first. Usa MatchBikes.com para compararla con opciones triathlon cercanas.
6.5
Valoración

Image 1 of 6
Score Summary
Rendimiento
6.1
Valor
9.8
Ajuste
5.6
Rendimiento
Built for speed and efficiency
Velocidad
7.3
Alta
Eficiencia en subida
5.1
Polivalente
Aerodinámica
10.0
Aero total
Ajuste
Dialed-in Fit & Comfort
Posición de conducción
7.6
Deportiva
Flexibilidad de ajuste
5.2
Moderadamente ajustable
Comodidad
2.5
Rígida de carrera
Valor
Relación calidad-precio
9.8
Valor excepcional
Rango de superficie
Solo carreteraEspecificaciones
General
Marca
Canyon
Modelo
Speedmax CF 8 Disc Di2
Año
2024
Precio
$6,299
Peso
9.11 kg
Categoría
Road
Subcategoría
Triathlon
Grupo
Ultegra Di2, Dura-Ace Di2
Cuadro
Cuadro
Canyon Speedmax CF Disc, Aero frame shaped by extensive computational fluid dynamics analysis, validated in the wind tunnel with our aero partners Swiss Side. Internal cable routing, 12x142 mm through axle (rear), flat-mount disc standard., Weight: 1380 g
Horquilla de Suspensión
Canyon FK0077 CF Disc, Aero-optimised deep-profile design, 12x100 mm through axle (front), flat-mount disc standard. CT scanner tested and approved., Axle dimension: 12x100 mm, Fork steer tube diameter: 1 1/8", Tyre Clearance: 30MM, Material: Carbon (CF)
Tipo de suspensión
Rigid
Transmisión
Palancas de Cambio
Shimano Dura-Ace Di2 R9160 Remote TT
Desviador Trasero
Shimano Ultegra Di2 R8150, 12-speed
Desviador Delantero
Shimano Ultegra Di2 R8150, 12-speed
Cassette
Shimano Ultegra R8100,12-speed, 11-30T, Number of sprockets: 12, Range: 11-30 | Shimano CS-R8100 Ultegra 12-speed Cassette
Biela
Shimano Ultegra R8100 4iiii Precision Powermeter, Number of chainrings: 2
Eje de Pedalier
Shimano Pressfit BB72, Bottom bracket standard: PF 86,5, Weight: 40 g | Ceramicspeed BB86 Shimano PressFit Bottom Bracket | Shimano SM-BB72-41B II Press-Fit Bottom Bracket
Cadena
Shimano CN-M8100 12s | Shimano SM-CN910 12-speed Quick-Link Chain Connector | Shimano CN-M8100 12-speed Chain 138 Links
Ruedas
Llantas
DT Swiss ARC 1400 Dicut, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 62 mm, Weight: 817 g | DT Swiss ARC 1400 Dicut, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 80 mm, Weight: 978 g
Neumáticos
Continental Grand Prix 5000, 25 mm, Width: 25mm, Weight: 220 g | Continental Grand Prix 5000, 28 mm, Width: 28mm, Weight: 260 g | Continental GP 5000 27.5" & 28" Road Tyre | Continental GP 5000 27.5" & 28" Road Tyre | Continental GP 5000 27.5" & 28" Road Tyre | Continental GP 5000 27.5" & 28" Road Tyre
Frenos
Tipo de freno
Hydraulic Disc
Descripción del freno
Shimano Flat Mount Adapter +20mm
Palancas de Freno
Shimano Dura-Ace Di2 R9180
Cockpit
Potencia
Canyon V21, Exclusively designed for our Speedmax CF range., Angle: -17°, Clamping diameter: 31.8 mm,, Weight: 199 g
Manillar
Canyon HB0053 Triathlon Basebar, Aerodynamically optimsed triathlon handlebar with direct mount spacer system featuring the Aeria Ultimate Race Bracket by Profile Design., Type: Flat, Basebar Rise: 0 mm
Asiento
Sillín
Selle Italia Watt Superflow
Tija de Sillín
Canyon SP0048 Aero Seatpost, Speedmax time trial seatpost, deep profile, large adjustment range, UCI compliant., Weight: 300 g
Geometría
| Medida | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.289 mm | 1.291 mm | 1.295 mm | 1.305 mm | 1.299 mm |
| Front Center | 552 mm | 579 mm | 605 mm | 637 mm | 671 mm |
| Rake | 34 mm | 34 mm | 34 mm | 34 mm | 34 mm |
| Trail | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Stack | 482 mm | 519 mm | 544 mm | 578 mm | 608 mm |
| Reach | 374 mm | 402 mm | 420 mm | 443 mm | 468 mm |
| Top Tube Length | 454 mm | 489 mm | 511 mm | 540 mm | 570 mm |
| Seat Tube Angle | 80.5 ° | 80.5 ° | 80.5 ° | 80.5 ° | 80.5 ° |
| Seat Tube Length | 480 mm | 518 mm | 543 mm | 577 mm | 607 mm |
| Head Tube Angle | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 113 mm | 115 mm | 140 mm | 176 mm | 207 mm |
| Chainstay Length | 410 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 956 mm | 988 mm | 1014 mm | 1047 mm | 1081 mm |
| Bottom Bracket Drop | 52 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 754 mm | 791 mm | 815 mm | 849 mm | 879 mm |
| Wheels | 650 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 175 cm | 187 cm | 197 cm | cm |
