Speedmax CFR TT
Canyon
Triathlon
Speedmax CFR TT es una bicicleta de triatlón (2024) de Canyon, de la serie Speedmax. Esta bici está orientada a quienes quieren sensaciones deportivas sin un ajuste de carrera extremo. Postura: deportiva. Terreno: ideal en asfalto. A nivel de métricas, sobresale por un montaje claramente orientado al aero para ir más rápido en carretera, gran potencial de velocidad en terreno rodador y capacidad de subida equilibrada. Lo que sacrifica un poco es una sensación más firme que opciones comfort-first y el value depende más de prioridades que del precio puro. Usa MatchBikes.com para compararla con opciones triathlon cercanas.
5.5
Valoración

Image 1 of 6
Score Summary
Rendimiento
6.1
Valor
2.9
Ajuste
5.6
Rendimiento
Built for speed and efficiency
Velocidad
7.1
Alta
Eficiencia en subida
5.3
Polivalente
Aerodinámica
10.0
Aero total
Ajuste
Dialed-in Fit & Comfort
Posición de conducción
7.8
Deportiva
Flexibilidad de ajuste
5.0
Moderadamente ajustable
Comodidad
2.5
Rígida de carrera
Valor
Relación calidad-precio
2.9
Sobrevalorada
Rango de superficie
Solo carreteraEspecificaciones
General
Marca
Canyon
Modelo
Speedmax CFR TT
Año
2024
Precio
$12,600
Peso
8.66 kg
Categoría
Road
Subcategoría
Triathlon
Grupo
Dura-Ace Di2
Ruedas
700c
Cuadro
Cuadro
Canyon Speedmax CFR TT Disc, Canyon Factory Racing triathlon carbon frame, featuring ultra-rare Toray M40X carbon fibres. Shaped by extensive computational fluid dynamics analysis with our aero partners Swiss Side, validated in the wind tunnel. Fully internal routing, 12x142 mm through axle, flat-mount disc standard. UCI-legal design., Weight: 1030 g (size M)
Horquilla de Suspensión
Canyon FK0079 CF Disc, UCI-legal deep-profile fork. Shaped and tested by our partner Swiss Side with use of extensive computational fluid dynamics analysis., Fork steer tube diameter: 1 1/4", Tyre Clearance: 30MM, Material: Carbon (CF)
Tipo de suspensión
Rigid
Transmisión
Palancas de Cambio
Shimano Dura-Ace Di2 R9160 Remote TT
Desviador Trasero
Shimano Dura-Ace R9200, 12-speed | Shimano Dura-Ace Di2 R9250, 12-speed
Desviador Delantero
Shimano Dura-Ace Di2 R9250
Cassette
Shimano Dura-Ace R9200, 12-speed, 11-30, Number of sprockets: 12, Range: 11-30 | Shimano CS-R9200 Dura-Ace 12-speed Cassette 11-30
Biela
Shimano Dura-Ace Di2 R9200 Powermeter, Number of chainrings: 2
Eje de Pedalier
Ceramicspeed BB86 Coated | Ceramicspeed BB86 Shimano PressFit Bottom Bracket
Cadena
Shimano M9100 12-speed, The latest generation of Shimano chains. With SIL-TEC treatment for extended durability. | Shimano SM-CN910 12-speed Quick-Link Chain Connector | Shimano XTR CN-M9100 12-speed Chain 138 Links
Ruedas
Llantas
DT Swiss ARC 1100 Dicut, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 80 mm, Weight: 820 g | DT Swiss ARC 1100 Disc, SH11, Rotor mount: Center Lock, Weight: 1.07 kg
Neumáticos
Schwalbe Pro One, 25mm, Width: 25mm, Weight: 235 g | Schwalbe Pro One, 28mm, Width: 28mm, Weight: 250 g | Continental GP 5000S TR TL 28" Road Tyre 28mm | Continental GP 5000S TR TL 28" Road Tyre 25mm
Frenos
Tipo de freno
Hydraulic Disc
Descripción del freno
Shimano Flat Mount Adapter +20mm
Palancas de Freno
Shimano Dura-Ace Di2 R9180
Cockpit
Potencia
Canyon V19 Short, Aluminium stem specially designed for use Canyon Speedmax bikes., Length: 65 mm, Weight: 204 g
Manillar
Canyon HB0054 Basebar flat, Time trial-specific handlebar with optimum aerodynamics, comfort, and adjustability. The narrow 390 mm basebar reduces the bike’s frontal area and is designed using CFD analysis to work together optimally with the frameset., Weight: 275 g.
Puños
Canyon Grip V01 Right Round | Canyon Grip V01 Left Round
Asiento
Sillín
Selle Italia Watt Kit Carbonio Superflow
Tija de Sillín
Canyon SP0048 Aero Seatpost, Speedmax time trial seatpost, deep profile, large adjustment range, UCI compliant., Weight: 300 g
Geometría
| Medida | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.151 mm | 1.132 mm | 1.14 mm | 1.157 mm |
| Bottom Bracket Height | 261 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 566 mm | 579 mm | 605 mm | 637 mm |
| Rake | 35 mm | 33 mm | 34 mm | 34 mm |
| Trail | 66 mm | 68 mm | 67 mm | 67 mm |
| Stack | 466 mm | 472 mm | 496 mm | 530 mm |
| Reach | 405 mm | 417 mm | 435 mm | 458 mm |
| Top Tube Length | 461 mm | 496 mm | 518 mm | 546 mm |
| Seat Tube Angle | 86 ° | 80.5 ° | 80.5 ° | 80.5 ° |
| Seat Tube Length | 474 mm | 518 mm | 540 mm | 570 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 59 mm | 65 mm | 91 mm | 126 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 974 mm | 988 mm | 1014 mm | 1047 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 767 mm | 791 mm | 815 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Max Height | 166 cm | 176 cm | 186 cm | cm |
