Planet X Tempest SRAM Rival 1 Titanium
planetx
Gravel
Planet X Tempest SRAM Rival 1 Titanium is a titanium gravel road bike (2024), by Planetx, from the Planet lineup. This setup will suit a wide range of riders thanks to its fit flexibility, leaning toward a balanced riding position, and is ready for gravel routes as well as pavement. Its profile is strongest in areas like strong value-for-money versus many similar bikes, good fit flexibility for dialing in rider position, and a balanced ride feel between comfort and directness. The main trade-off is less emphasis on outright speed than speed-focused builds. Next step: compare this bike with other gravel models on MatchBikes.com.
5.6
Rating

Image 1 of 6
Score Summary
Performance
2.9
Value
9.7
Fit
6.7
Performance
Built for speed and efficiency
Speed
3.6
Very Low
Climbing Efficiency
3.3
Hefty but Manageable
Aerodynamics
4.7
Minimal Aero
Fit
Dialed-in Fit & Comfort
Riding Position
6.6
Balanced
Fit Flexibility
7.7
Adjustable
Ride Comfort
5.9
Balanced
Value
Value for Money
9.7
Exceptional Value
Surface Range
Gravel ReadySpecifications
General
Brand
planetx
Model
Planet X Tempest SRAM Rival 1 Titanium
Year
2024
Price
$2,496
Category
Road
Sub Category
Gravel
Groupset
Rival
Frame
Frame
Planet X Tempest Titanium Gravel Road Frame / Medium
Suspension Fork
Selcof Carbon Gravel Fork / Tapered-12mm Thru
Suspension Type
Rigid
Drivetrain
Rear Derailleur
SRAM Rival 1 Rear Mech / Long Cage
Cassette
SRAM PG1130 Cassette / 11-42T
Crank
SRAM Rival 1 GXP Chainset (No BB) / 172.5mm / 42t
Bottom Bracket
SRAM GXP XR Bottom Bracket (With Spacers) / 68/73mm
Chain
SRAM PC1110 11 Speed Chain / 116 Links
Wheels
Rims
Fulcrum Rapid Red 900
Tires
WTB Nano 700c Wired Tyre / 40mm / Black
Brakes
Brake Type
Hydraulic Disc
Brake Description
SRAM Flat Mount Disc Brake Mounting Hardware / 27mm / Single
Cockpit
Stem
Selcof Zeta 6061 Alloy Stem / 100mm / 31.8mm / 7 Degree
Handlebar
Selcof Sterrato V2 Flared Gravel Handlebar / 42cm
Seat
Saddle
San Marco Monza Start Saddle / Black / Carbon Steel
Seatpost
Selcof Zeta 6061 Alloy Seatpost / 27.2mm / 350mm
Geometry
| Measurement | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.426 mm | 1.41 mm | 1.428 mm | 1.486 mm | 1.472 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 588 mm | 599 mm | 610 mm | 620 mm | 630 mm |
| Rake | 44 mm | 44 mm | 44 mm | 45 mm | 45 mm |
| Trail | 77 mm | 74 mm | 74 mm | 69 mm | 66 mm |
| Stack | 532 mm | 543 mm | 557 mm | 587 mm | 599 mm |
| Reach | 373 mm | 385 mm | 390 mm | 395 mm | 407 mm |
| Top Tube Length | 520 mm | 535 mm | 550 mm | 570 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 155 mm | 165 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1018 mm | 1029 mm | 1039 mm | 1050 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
