Planet X EC-130 Shimano Ultegra Di2
planetx
Aero
Planet X EC-130 Shimano Ultegra Di2 is a carbon aero road bike (2023), from Planetx, part of the Planet family. It is a strong match for riders who want a sporty road feel without a full race fit, leaning toward a sporty riding position, and is best matched to paved roads. Its profile is strongest in areas like a clearly aero-focused setup for faster road riding, strong speed potential on smoother terrain, and good fit flexibility for dialing in rider position. The main limitation versus more focused builds is a firmer ride feel than comfort-first options. Compare this bike with other aero bikes on MatchBikes.com.
6.1
Rating

+3
Image 1 of 9
Score Summary
Performance
6.0
Value
7.0
Fit
5.8
Performance
Built for speed and efficiency
Speed
7.9
High
Climbing Efficiency
2.8
Hefty but Manageable
Aerodynamics
9.2
Full Aero
Fit
Dialed-in Fit & Comfort
Riding Position
6.5
Sporty
Fit Flexibility
7.6
Adjustable
Ride Comfort
2.2
Race-Stiff
Value
Value for Money
7.0
Fair Value
Surface Range
Road OnlySpecifications
General
Brand
planetx
Model
Planet X EC-130 Shimano Ultegra Di2
Year
2023
Price
$4,868
Category
Road
Sub Category
Aero
Groupset
Ultegra Di2
Wheels
700c
Frame
Frame
Carbon
Suspension Type
Rigid
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 RD-R8150 GS 12-Speed Rear Mech
Front Derailleur
Shimano Ultegra Di2 FD-R8150 Braze On Front Mech
Cassette
Shimano CS-R8100 12-Speed 11-34 Cassette
Crank
Shimano Ultegra FC-R8100 Chainset / 172.5mm / 52/36T
Bottom Bracket
Shimano SM-BBR60 BSA Bottom Bracket
Chain
Shimano CN-M8100-12 Speed Chain 120L
Wheels
Rims
Fulcrum Racing 400 Disc 700c Centrelock Wheelset / Front 12mm / Rear 12 X 142mm / Shimano 11 Speed
Tires
Hutchinson Challenger 700c Folding Tyre / 25mm / Black
Brakes
Brake Type
Hydraulic Disc
Brake Description
Hydraulic Disc
Cockpit
Handlebar
Prologo Plain Touch Bar Tape / Black
Seat
Saddle
San Marco Shortfit Open-Fit Start-Up Superwide Saddle / Xsilite Rail
Seatpost
Aero
Geometry
| Measurement | XSM | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.42 mm | 1.44 mm | 1.46 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 579 mm | 582 mm | 591 mm | 599 mm | 615 mm |
| Rake | 42 mm | 44 mm | 43 mm | 33 mm | 43 mm |
| Trail | 71 mm | 66 mm | 64 mm | 71 mm | 61 mm |
| Stack | 505 mm | 516 mm | 537 mm | 557 mm | 577 mm |
| Reach | 370 mm | 372 mm | 378 mm | 387 mm | 396 mm |
| Top Tube Length | 507 mm | 523 mm | 535 mm | 554 mm | 569 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 105 mm | 115 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm | 398 mm |
| Wheelbase | 966 mm | 969 mm | 976 mm | 977 mm | 1002 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
