Signal Peak TR Comp Shimano
Fezzari
Crosscountry
Signal Peak TR Comp Shimano è una MTB cross-country (2023) by Fezzari. In pratica è un ottimo match per chi cerca un feeling off-road più attivo e orientato alla performance. Postura: sportiva e attiva. Terreno: ideale su trail scorrevoli. A livello di metriche, spicca per un feeling più confortevole sulle lunghe, capacità in salita da all-rounder e sospensioni capaci su terreno sconnesso. Detto questo, Il compromesso principale è meno focus sulla velocità pura rispetto ai setup più race e il value dipende più dalle priorità che dal solo prezzo. Usa MatchBikes.com per confrontarla con alternative cross-country vicine.
5.8
Valutazione

Image 1 of 4
Score Summary
Prestazioni
6.0
Valore
3.5
Vestibilità
7.2
Prestazioni
Built for speed and efficiency
Velocità
4.8
Molto bassa
Efficienza in Salita
7.0
Tuttofare
Sospensione
6.0
Controllo sicuro sui trail
Vestibilità
Dialed-in Fit & Comfort
Posizione di Guida
7.0
Sportiva
Flessibilità Vestibilità
6.9
Moderatamente regolabile
Comfort di Guida
7.5
Confortevole
Valore
Rapporto Qualità-Prezzo
3.5
Sovrapprezzata
Gamma Superfici
Trail scorrevoliSpecifiche
Generale
Marca
Fezzari
Modello
Signal Peak TR Comp Shimano
Anno
2023
Prezzo
$3,799
Categoria
Mountain
Sottocategoria
Crosscountry
Gruppo
SLX, Shimano
Ruote
29"
Telaio
Telaio
Fezzari Signal Peak CleanCast™ Carbon TetraLink™ Full Suspension, 115mm travel. Internal FutureProof™ cable routing on top of Downtube. CleanCatch™ rattle-proof cable guides. UDH derailleur hanger. ISCG-05 mounts, two hole. 2 flush-mount bottle cages (all frame sizes)
Forcella Ammortizzata
DVO Sapphire D1 120mm Travel, 110x15mm thru axle, tapered steerer
Ammortizzatore Posteriore
DVO Opal T2 115mm, Custom Tuned
Tipo di sospensione
Full
Trasmissione
Leve del Cambio
Shimano SLX Trigger 12-Speed
Deragliatore Posteriore
Shimano SLX 12-Speed
Cassetta
Shimano SLX, 10-51T, 12-speed
Guarnitura
Shimano FC-MT510-1
Movimento Centrale
Shimano BB-MT501 English Thread
Catena
Shimano SLX 12-speed
Ruote
Mozzo Anteriore
F: Bear Pawls Sealed Bearing Disc, 110x15mm thru axle, 32 hole, 6 bolt; R: Bear Pawls Sealed Bearing Disc, 148x12mm thru axle, 32 hole, 6 bolt
Mozzo Posteriore
F: Bear Pawls Sealed Bearing Disc, 110x15mm thru axle, 32 hole, 6 bolt; R: Bear Pawls Sealed Bearing Disc, 148x12mm thru axle, 32 hole, 6 bolt
Cerchi
Stans Flow D 29 disc specific, tubeless ready
Raggi
15G Stainless, black, with brass nipple
Pneumatici
Maxxis Minion DHF 29x2.5, EXO, TR Protection, Tubeless Ready, Aggressor 29x2.5, EXO, TR Protection, Tubeless Ready
Freni
Tipo di freno
Hydraulic Disc
Descrizione del freno
SRAM DB8, 180mm/160 F/R rotors
Cockpit
Attacco Manubrio
Fezzari CNC35 stem
Manubrio
Fezzari team 35mm bar. Customized sizing through 23-Point Custom Setup
Seduta
Sella
Ergon SM10
Reggisella
PNW Rainier Dropper- customized sizing through 23-Point Custom Setup
Geometria
| Misura | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 720 mm | 737 mm | 759 mm | 780 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 611 mm | 617 mm | 626 mm | 635 mm |
| Reach | 437 mm | 453 mm | 471 mm | 488 mm |
| Top Tube Length | 598 mm | 615 mm | 634 mm | 653 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 425 mm | 455 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 125 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1153 mm | 1170 mm | 1192 mm | 1213 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 735 mm | 740 mm | 750 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
